Home > Stainless Steel > Stainless steel 310H Welded Tubing
Bereket Pipes, a top-notch manufacturer and supplier based in Addis Ababa, Ethiopia, specializes in high-quality Stainless Steel 310H Welded Tubing, perfect for high-temperature and industrial uses. These tubes are crafted with precision welding techniques, ensuring they are strong, consistent, and reliable for thermal and chemical processes. Whether it’s for heat exchangers, furnace components, or high-temperature piping systems, 310H welded tubing stands out for its durability, corrosion resistance, and dimensional stability. With a blend of advanced metallurgical knowledge and strict quality control, Bereket Pipes delivers a locally sourced solution that meets international standards and performs exceptionally well in tough industrial settings.
Stainless Steel 310H Welded Tubing is an austenitic alloy that contains about 24–26% chromium and 19–22% nickel, with a controlled carbon content of around 0.08% to boost its high-temperature strength. It boasts a tensile strength ranging from 515 to 650 MPa, a yield strength of 205 to 275 MPa, and an elongation of 35 to 45%, ensuring it remains mechanically stable even under thermal cycling and pressure. This alloy excels in resisting oxidation, scaling, and corrosion in high-temperature conditions. Thanks to precision welding, the tube maintains its mechanical integrity while being cost-effective to produce, making it ideal for heat exchangers, boilers, and industrial piping applications that demand reliable high-temperature performance.
| 310H Stainless Steel Tube Finish | Polished, BA (Bright & Annealed),AP (Annealed & Pickled), MF |
|---|---|
| Stainless Steel 310H Tube Standards | ASTM A213,ASTM A269, ASTM A249,ASME SA213,ASME SA269, ASME SA249, NACE MR0175/ISO 15156, PED 97/23/EC,EN 10216-5 TC1 / TC2, AD 2000 |
| Stainless Steel 310H Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| 310H stainless steel tubing End | Plain End, Beveled End, Treaded, Ends are suitable for orbital welding |
| Marking | All 310H Stainless Steel tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Stainless Steel 310H Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Stainless Steel 310H tubing wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Stainless Steel 310H tube Form | Straight or ‘U’ bent Tubes, Round,Boiler, Coil , LSAW Tubes, Square, Hydraulic, Rectangular, Hollow Etc. |
| Stainless Steel 310H Tube Type | EFW, Seamless , Fabricated, ERW, Welded |
| SS 310H tube Length | Single Random , Standard & Cut length , Double Random |
| Non-Electropolished | (CFOS) Cleaned for Oxygen Grade Service or Corrosive Systems, (BA) Bright Annealed or (AP) Annealed & Pickled for High-Purity |
| I.D. Surface Finish Options | 5, 7 & 10 µin. Ra |
| 310H stainless steel tubing Testing & Inspection | Visual inspection • Surface roughness measurement • Helium-leak testing • Scanning Electron Microscopy (SEM) • Auger Electron Microscopy (AES) • Election Spectroscopy for Chemical Analysis (ESCA or XPS) • Particle testing • Moisture testing |
| Tolerances | In accordance with: ASTM: A269 & A632, JIS: G 3459 |
| 310H stainless steel tubing Test Certificate | Laboratory Test Certificate from Govt. Approved Lab. Manufacturer Test Certificate according to EN 10204 3.1 B Under Third Party Inspection |
| Electropolished | (EP) Electropolished for Ultra High Purity Systems |
| 310H stainless steel tubingApplication | Oil Tube , Boiler and Heatexchange , Gas Tube, Fluid Tuber |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 310H | min. | 0.04 | – | – | – | – | 24.0 | – | 19.0 | – |
| max. | 0.10 | 2.0 | 1.0 | 0.045 | 0.030 | 26.0 | 21.0 | – | ||
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 310H | 515 | 205 | 40 | 95 | 217 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Stainless Steel 310H Welded Tubing from Bereket Pipes and Tubes for exceptional corrosion resistance, superior strength and excellent durability. Ideal for a variety of industrial applications it provides outstanding performance in harsh environments. With precision manufacturing and quality assurance, we ensure reliable and durable tubing solutions.
Bereket Pipes and Tubes is the largest supplier of Stainless Steel 310H Welded Tubing in Addis Ababa, Ethiopia. Known for its high-quality products. We offer superior corrosion resistance, strength, and durability. Trusted by industries worldwide they provide reliable precision-engineered tubing for various applications and project needs.
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 310H | S31009 | – | X5CrNi18-10 | 2332 | SUS 310H | ||
Yes, Bereket Pipes and Tubes offer large custom designs for Stainless Steel 310H Welded Tubing. With design, wall thickness and length. Their adjustable options ensure the tubing meets specific application requirements. This flexibility makes it more efficient and reliable for different industries and environments. For more details, contact us at sales@bereketpipes.com.
Stainless Steel 310H Welded Tubing finds its place in various industries where high-temperature performance, corrosion resistance, and durability are crucial. You’ll commonly see it in furnace and kiln components, heat exchangers, superheaters, boilers, and gas ducting in power plants, as well as in chemical and petrochemical facilities. Its welded design allows for cost-effective manufacturing, making it suitable for medium-pressure and high-temperature applications.
