Home > Super Duplex Steel > Super Duplex Steel Pipe
Bereket Pipes, a well-respected manufacturer and supplier located in Addis Ababa, Ethiopia, specializes in top-notch Super Duplex Steel Pipes that are built for outstanding strength and resistance to corrosion. These pipes are crafted to perform reliably even in the toughest industrial settings, such as marine, chemical, and oil & gas industries. Thanks to their cutting-edge manufacturing techniques and rigorous quality control, Bereket Pipes guarantees exceptional dimensional accuracy, durability, and resistance to stress corrosion cracking. Their Super Duplex Steel Pipes are perfect for high-pressure and high-temperature applications, making them a go-to choice for industries that demand long-lasting performance and dependability.
Super Duplex Steel Pipes are primarily made up of chromium (25%), nickel (7%), molybdenum (4%), and nitrogen, which together provide remarkable mechanical strength and corrosion resistance. They boast high yield and tensile strength, impressive toughness, and excellent resistance to pitting and crevice corrosion. These pipes also retain great weldability and fatigue strength, even in challenging environments. The unique combination of austenitic and ferritic microstructures delivers an ideal balance of ductility, hardness, and thermal stability.
| Specifications | ASTM A 789 ASME SA 789 |
|---|---|
| Standard | AISI, DIN, EN, GB, JIS, ASTM, ASME Super Duplex 2507 Pipe |
| 2507 Seamless Pipe Outer Diameter | 6.00 mm OD up to 250 mm OD, Sizes up to 12” NB |
| Alloy 2507 Welded Pipe size | 5.0 mm – 1219.2 mm |
| 2507 EFW Pipe size | 5.0 mm – 1219.2 mm |
| Thickness | 0.3mm – 50 mm |
| SS 2507 Seamless Tube Size | 3.35 mm OD To 101.6 mm OD, 15 NB to 150 NB IN |
| 2507 Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| DSS 2507 tubing wall thickness | 0.020″ –0.220″ (special wall thicknesses available) |
| 2507 Pipe Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Duplex 2507 Pipe & Tube Finish | Polished, AP (Annealed & Pickled), MF, NO.1, NO.4, BA (Bright & Annealed), 2B, BA, HL, 8K, Mirror finish,etc |
| 2507 Pipe & Tube Form | Round, Hollow, Square,Rectangular, Hydraulic, Coiled, Straight Pipes, “U” Shape, Pan Cake Coils etc. |
| Super Duplex 2507 Pipe & Tube Length | Single Random, Double Random, Standard & Cut length |
| 2507 Pipe & Tube End | Beveled End,Plain End, Treaded. |
| 2507 Pipe & Tube Type | 2507 Seamless / ERW/ Welded / Fabricated / EFW / CDW / DOM / CEW Pipes |
| Marking | All 2507 Pipes are marked as follows: Grade, Standard, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Super Duplex 2507 Tube Application | Oil Tube, Gas Tube, Fluid Tube, Boiler and Heatexchanger |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Specialized in | Large Dia 2507 Pipe 2507 Capillary Tube & Other Odd Size 2507 Super Duplex Heat Exchanger & Condenser Tubes |
| Super Duplex | C | N | P | Si | Mn | Mo | Ni | Cr | S | Other |
| 0.030 | 0.24/0.32 | 0.035 | 0.80 | 1.20 | 3.0/5.0 | 6.00/8.00 | 24.0/26.0 | 0.020 | Cu:0.50 |
| Super Duplex | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
You’ll find Super Duplex Steel Pipes being widely utilized in chemical processing, offshore oil and gas production, desalination plants, and power generation sectors. Their exceptional resistance to chloride stress corrosion cracking makes them perfect for seawater systems, heat exchangers, and pressure vessels. They’re also employed in pipelines for transporting corrosive fluids, refineries, and the pulp & paper industries, where durability and performance are crucial. These pipes promise a long service life, low maintenance costs, and reliability even under extreme pressure and temperature conditions.
Bereket Pipes and Tubes, one of the largest suppliers of Super Duplex Steel Pipes in Addis Ababa, Ethiopia, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Super Duplex Steel Pipes to meet your specific requirements. Our team at Bereket Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@bereketpipes.com.
| Wall | Sizes ( O.D.) |
|---|---|
| .010 | 1/16″ , 1/8″ , 3/16″ |
| .020 | 1/16″ , 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ |
| .012 | 1/8″ |
| .016 | 1/8″ , 3/16″ |
| .028 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 3/4″ , 1″ , 1 1/2″ , 2″ |
| .035 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 7/16″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .049 | 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/8″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .065 | 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 3/4″ , 2″ , 2 1/2″ , 3″ |
| .083 | 1/4″ , 3/8″ , 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 7/8″ , 2″ , 2 1/2″ ,3″ |
| .095 | 1/2″ , 5/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .109 | 1/2″ , 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .120 | 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 2 1/4″ , 2 1/2″ , 3″ |
| .125 | 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 3″ , 3 1/4″ |
| .134 | 1″ |
| .250 | 3″ |
| .375 | 3 1/2″ |
Super Duplex Steel Pipes find extensive use in industries where strength and corrosion resistance are crucial. In the oil & gas sector, they are essential for offshore platforms, subsea pipelines, and processing systems. The petrochemical and chemical industries rely on them for transporting corrosive fluids, heat exchangers, and pressure vessels. In marine applications, they are utilized in desalination plants, shipbuilding, and seawater cooling systems due to their remarkable resistance to chloride-rich environments. Power generation plants also depend on these pipes for boilers and other critical components, ensuring efficiency and reliability in their operations.
